Product Description ?Titanium foil is a titanium plate, strip, roll or sheet with a thickness of less than or equal to 0.1mm. The maximum width of rolled titanium foil is about 600mm. ?The width of the titanium foil is cut according to the requirements of the user.But the wider the manufacturing, the higher the productivity. ?Titanium foil is mainly used in aerospace, navigation, nuclear power, electronics, chemical industry, petroleum, precision manufacturing, medical pharmaceutical and other aspects.

Titanium Foil - Product Overview

We offer cold-rolled titanium foil in Gr1, Gr2 and Gr5 to ASTM B265, with thicknesses from 0.01 mm to 0.5 mm and widths up to 600 mm. Foils are bright annealed for a clean, uniform surface and precise thickness tolerance.

Key Features

Tight thickness tolerance and excellent surface quality; corrosion resistant and biocompatible; easy to stamp, form and deep draw; stable mechanical properties in coil form.

Typical Applications

Speaker diaphragms and acoustic components; medical and dental products; precision stamped parts, gaskets and seals; battery and electronics components; aerospace honeycomb core and scientific research.

Supply Capability

Standard foils are in stock for shipment within one day. Custom thicknesses and slitting to width are available, with full mill test certification supplied.

Product Details

DescriptionTitanium foil/titanium strip
Material

Gr1, Gr2, Gr3,Gr4,Gr5, Gr7, Gr6,Gr9, Gr11, Gr12 ,Gr16, Gr17,Gr25

TA0,TA1,TA2,TA5,TA6,TA7,TA9,TA10,TB2,TC1,TC2,TC3,TC4

StandardASTM B265,ASME SB265,DIN17851,TiA16Zr5Mo1.5,JIS4100-2007,GB3461-2007
Size

Thickness:0.01-2.0mm

Width:0.7-240mm

Length:according to requirements

MOQ1 Kilogram/Kilogrames
Equepment usedCNC lathes, Milling machine, Machining Center,Thread rolling machine Magnetic needle polishing machine
Features

1.high corrosion resistance

2.low density

3.non-ferromagnetic

4.good biocompatibility

PackageStandard export package,suit for all kinds of transport ,or as required.
Application

1.Based on High intensity,titanium products tensile strength can be up to 180Kg/mm2.

2.Titanium and titanium alloy in aviation industry, is called "space metal"; In addition,

in the shipbuilding industry, chemical industry, manufacturing machinery parts,

telecommunications equipment, hard alloy, etc have increasingly extensive application

3.In addition, because of the titanium alloy with the human body has very good compatibility,

so the titanium alloy can also be artificial bone.

Chemical Composition:

Composition (%)CNFeOHAlVTi
GR1≤0.08≤0.03≤0.20≤0.18

≤0.015

--Bal.
GR2≤0.08≤0.03≤0.30≤0.25≤0.015--Bal.
GR5≤0.10≤0.05≤0.30≤0.20≤0.0155.50-6.803.50-4.50Bal.

Tensile Requirement :

GradeTensile StrengthYield Strength 0.2% OffsetElongation
in 2 in.or 50mm min.%		Bend Test
MinMinMinMaxUnder 0.070 in.(1.8mm)in thickness0.070 to 0.187 in.
(1.8 to 4.75mm)in thickness
KsiMpaKsiMpaKsiMpa
1352402013845310241.5T2T
2503454027565450202T2.5T
3654505538080550182T2.5T
4805507048395655152.5T3T


Specifications

package
Packaging & Delivery Packaging Details 1. Wooden case 2. Available upon the client's request.
