Advantage & Service 1)Professional manufacturer 2)Quality and Innovation, Technology 3)Customized design is available, and OEM&ODM are welcomed 4)Timely/Prompt Delivery.Competitive Prices 5)Quality guarantee for each item from our company is established 6)Exclusive and unique solution can be provided to our customer 7)We are dedicated to offering our customers the safest and easiest buying experience

Titanium Plate and Sheet - Product Overview

Our titanium plates and sheets are manufactured to ASTM B265, AMS 4911 and ASME SB265 standards in commercially pure grades (Gr1 to Gr4) and alloyed grades including Gr5 (Ti-6Al-4V), Gr7 and Gr12. Available in thicknesses from 0.5 mm to 100 mm, widths up to 2,000 mm and lengths up to 6,000 mm, supplied in hot-rolled, cold-rolled or annealed condition.

Key Features

About 45 percent lighter than steel at comparable strength; outstanding resistance to seawater, chlorides and oxidizing acids; excellent fatigue strength and fracture toughness; good formability in the softer commercially pure grades.

Typical Applications

Aerospace skins and structural components; chemical and petrochemical pressure vessels, tanks and heat exchanger plates; marine and offshore equipment; medical implants and surgical instruments; power plant condensers, desalination plants, chlor-alkali cells and architectural cladding.

Supply Capability

Standard sizes are in stock for shipment within one day. We offer cut-to-size, waterjet and laser cutting, surface grinding and pickling, with EN 10204 3.1 mill test certificates supplied for every batch.

Product Details

Product Description
  • Name: titanium sheet
  • Applications:chemical, medical, aviation, industry
  • Size:
    • Thickness: 3mm
    • Width:1000-1200mm
    • Length: 2500mm maximum
  • Ti (minimum): >99.6%
  • Technique: cold rolled
  • Packing details: wooden cases
  • Port: Tianjin, Shanghai, Qingdao
  • Delivery time: 35 days as per customer's requirements

High quality Titanium plate

Product

Titanium plate

Grade

GR1, GR2, GR3, GR4, GR5, 6AL4V Eli, GR7, GR9, GR12, GR23,TB3, TB6, TC4, TC6, TC11, TC17, TC18

Standard

ASTM B265, ASTM SB265, AMS4911, GB/T3622-199

Specification

Hot Rolling: Length 1000-4000mm,Width 400-3000mm,Thickness 4.1-60mm
Cold Rolling:Length 1000-3000mm,Width 400-1500mm,Thickness 0.3-3.0mm

Payment

T/T, L/C at sight, as your inquiry

Certificate

ISO 9001:2008,AS 9100

Surface

Pickled, Polished, Sandblasted.

In stock

ASTM B265

Standard size: 1000 x 2000MM

Thickness: 0.5-20MM

Ti grade chemical componentHigh quality Titanium plate


NCHFeOAlVPaMoNiTi
Gr 10.030.080.0150.20.18/////bal
Gr 20.030.080.0150.30.25/////bal
Gr 50.050.080.0150.40.25.5~6.753.5~4.5///bal
Gr 70.030.080.0150.30.25//0.12~0.25//bal
Gr 90.030.080.0150.250.152.5~3.52.0~3.0///bal
Gr120.030.080.0150.30.25///0.2~0.40.6~0.9bal
Titanium Benefits
  • High resistance to pitting, crevice corrosion resistance
  • High resistance to stress corrosion cracking, corrosion fatigue and erosion
  • Cold bending for complex piping bends without fittings or flanges

  • High strength to weight ratio

  • Weight saving possibilities
  • Low modulus, high fracture toughness and fatigue resistance
  • Suitability for coiling and laying on seabed
  • Ability to withstand hot/dry and cold/wet acid gas loading
  • Excellent resistance to corrosive and erosive action of high-temperature acid steam and brine
  • Good workability and weldability


Specifications

package
Packaging & Delivery Packaging Details 1. Wooden case 2. Available upon the client's request.
Baoji NewFuture Titanium Co., Ltd. New Future Metal supplies titanium and titanium alloy materials, pipes, rods, and wires in common sizes. With a large inventory in all standard sizes, and orders can be shipped within one day. We also provide services for materials such as Nickel and nickel alloy|Zirconium |Tantalum |Niobium And ancillary metal processing services, metal electrodes, equipment, special-shaped materials, etc. can be customized according to needs More about the company →
